INA 87414-M
Axial-Cylindrical Roller Bearings
Axial cylindrical roller bearing 874..-M, multi-row
(BRAND)：INA
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Main Dimensions & Performance Data
d
70 mm
Bore diameter
D
150 mm
Outside diameter
B
36 mm
Width
Ca
360,000 N
Basic dynamic load rating, axial
C0a
1,380,000 N
Basic static load rating, axial
CG
2,600 1/min
Limiting speed
nϑr
900 1/min
Reference speed
≈m
3.598 kg
Weight
Mounting dimensions
da min
147 mm
Minimum diameter shaft shoulder
da min
76 mm
Maximum diameter of housing shoulder
ra max
2 mm
Maximum recess radius
