SKF 305701 C-2RS1
Cam roller (yoke-type track roller) with flat outside surface, integral sealing and relubrication feature
(BRAND)：SKF
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Dimensions
D
35.0 mm
Outside diameter
d
12.0 mm
Bore diameter
B
15.9 mm
Width
d1
19.1 mm
Shoulder/recess diameter inner ring
D1
27.7 mm
Recess diameter outer ring
r1,2
0.6 mm
Chamfer dimension
a
19.0 mm
Distance pressure points
mass
0.0772 kg
Product net weight
