SKF SCF 30 ES
Rod end, requires maintenance, rectangular section welding shank
(BRAND)：SKF
(Availability)：In Stock
Dimensions
d
30.0 mm
Bore diameter
d2
66.5 mm
Diameter head
B
22.0 mm
Width inner ring
C1
29.0 mm
Width head
h2
51.0 mm
Height shank end face - centre rod end eye
α
6.0 °
Angle of tilt
dk
40.7 mm
Raceway diameter inner ring
l6
85.0 mm
Length (height) housing
r1
0.6 mm
Chamfer dimension bore
mass
0.825 kg
Product net weight
