SKF SCF 40 ES
Rod end, requires maintenance, rectangular section welding shank
(BRAND)：SKF
(Availability)：In Stock
Dimensions
d
40.0 mm
Bore diameter
d2
102.0 mm
Diameter head
B
28.0 mm
Width inner ring
C1
36.5 mm
Width head
h2
69.0 mm
Height shank end face - centre rod end eye
α
7.0 °
Angle of tilt
dk
53.0 mm
Raceway diameter inner ring
l6
121.0 mm
Length (height) housing
r1
0.6 mm
Chamfer dimension bore
mass
2.45 kg
Product net weight
