SKF SCF 90 ES
Rod end, requires maintenance, rectangular section welding shank
(BRAND)：SKF
(Availability)：In Stock
Dimensions
d
90.0 mm
Bore diameter
d2
228.5 mm
Diameter head
B
60.0 mm
Width inner ring
C1
67.0 mm
Width head
h2
150.0 mm
Height shank end face - centre rod end eye
α
5.0 °
Angle of tilt
dk
115.0 mm
Raceway diameter inner ring
l6
265.5 mm
Length (height) housing
r1
1.0 mm
Chamfer dimension bore
mass
23.5 kg
Product net weight
