SKF UNP250-2250-375-H9J
Single-acting polyurethane piston U-cup seal
(BRAND)：SKF
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Dimensions
D
69.85 mm
Cylinder bore diameter
d
57.15 mm
Piston groove diameter
L
10.48 mm
Piston groove width
L+H
13.65 mm
Additional groove width
H
9.53 mm
Nominal seal width
S
6.35 mm
Radial depth
R
0.51 mm
Groove radius
C
7.92 mm
Lead-in chamfer length
mass
0.013 kg
Product net weight
