Timken 293/600EM
Thrust Spherical Roller Bearings-Type TSR
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Specifications
d - Bore
600 mm
Bearing Type
Thrust Spherical Roller Bearings - TSR
Dimensions
D - Outside Diameter
900 mm
d1 - Cone Outside Diameter
840 mm
D1 - Cup Bore
720 mm
E - Shoulder Diameter - Housing (Max)
751 mm
H - Shoulder Diameter - Shaft (Min)
780 mm
r - Fillet Radius
6 mm
S - Dimension
335 mm
T - Total Width
180.2 mm
T1 - Cage Position
127.3 mm
T2 - Groove Position
65 mm
T3 - Cup Width
89 mm
Basic Load Ratings
Static Load Rating
32700000 N
Dynamic Load Rating
7380000 N
Thermal Speed Rating
330 rpm
