Timken NA64432SW – 64708D
Tapered Roller Bearings - TNA (Tapered Double, non-adjustable) Imperial
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Detailed data of
NA64432SW – 64708D
Specifications
Cone Part Number
NA64432SW
Cup Part Number
64708D
Design Unit
Inch
Dimensions
d - Bore
109.975 mm
D - Cup Outer Diameter
179.974 mm
T - Bearing Width across Cones
101.6 mm
C - Double Cup Width
69.85 mm
Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius1
3.5 mm
r - Cup Backface "To Clear" Radius2
0.8 mm
db - Cone Backface Backing Diameter
128 mm
Da - Cup Frontface Backing Diameter
173.99 mm
Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)3
65900 N
C1 - Dynamic Radial Rating (1 million revolutions)4
443000 N
C5
58300 N
C906
115000 N
Factors
K - Factor7
1.13
e - ISO Factor8
0.52
Y1 - ISO Factor9
1.31
Y2 - ISO Factor10
1.95
