Timken NA82587 – 82932D
Tapered Roller Bearings - TNA (Tapered Double, non-adjustable) Imperial
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Detailed data of
NA82587 – 82932D
Specifications
Cone Part Number
NA82587
Cup Part Number
82932D
Design Unit
Inch
Dimensions
d - Bore
149.225 mm
D - Cup Outer Diameter
236.538 mm
T - Bearing Width across Cones
131.762 mm
C - Double Cup Width
106.363 mm
Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius1
3.5 mm
r - Cup Backface "To Clear" Radius2
1.5 mm
db - Cone Backface Backing Diameter
169 mm
Da - Cup Frontface Backing Diameter
227.08 mm
Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)3
134000 N
C1 - Dynamic Radial Rating (1 million revolutions)4
897000 N
C5
101000 N
C906
232000 N
Factors
K - Factor7
1.32
e - ISO Factor8
0.44
Y1 - ISO Factor9
1.53
Y2 - ISO Factor10
2.27
