Timken AN 17-W 17
Inch Accessories - Locknut and Lockwasher
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Specifications
Bearing Bore
85 mm
Locknut
AN 17
Lockwasher
W 17
Threads
Major Diameter
84.84 mm
Threads No. per Inch
12
Shaft
Relief Diameter A
81.71 mm
Diameter S-3
80.96 mm
W1
4.37 mm
L2
14.27 mm
H3
3.2 mm
S4
9.53 mm
M5
6.35 mm
Locknut
C
112.04 mm
D
16.13 mm
Lockwasher
Q
1.57 mm
R
86.23 mm
B
117.48 mm
s
8.97 mm
