Timken AN 19-W 19
Inch Accessories - Locknut and Lockwasher
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Specifications
Bearing Bore
95 mm
Locknut
AN 19
Lockwasher
W 19
Threads
Major Diameter
94.74 mm
Threads No. per Inch
12
Shaft
Relief Diameter A
91.62 mm
Diameter S-3
90.49 mm
W1
4.37 mm
L2
17.45 mm
H3
4 mm
S4
9.53 mm
M5
6.35 mm
Locknut
C
125.55 mm
D
18.52 mm
Lockwasher
Q
2.13 mm
R
96.52 mm
B
132.56 mm
s
8.97 mm
