Timken S-4789-A
Thrust Cylindrical Roller Bearing-Type TP
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Specifications
d - Bore Diameter
174.625 mm
Bearing Type
Thrust Cylindrical Roller Bearings - TP
Note
Bearing includes special features; click on
Dimensions
D - Bearing O.D.
279.400 mm
T - Bearing Width
69.85 mm
T1 - Bearing Width
19.05 mm
d1 - Large Bore I.D.
174.63 mm
D1 - Small Diameter O.D.
279.4 mm
E - Shoulder Diameter - Housing
186.4 mm
H - Shoulder Diameter - Shaft
262.6 mm
r - Fillet Chamfer
1.6 mm
Basic Load Ratings
Static Load Rating
1400000 N
Dynamic Load Rating
1156000 N
Limiting Speed
1900 rpm
