INA AXW30
Axial-Needle Roller Bearings
Axial needle roller bearings, single direction, AXK with axial bearing washer
(BRAND)：INA
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Main Dimensions & Performance Data
Dc1
30 mm
Bore diameter cage
D
50 mm
Outside diameter bearing washer
B
3.2 mm
Height bearing
B1
4 mm
Height centering collar
D1
37 mm
Outside diameter centering collar
Ea
46 mm
Raceway dimension
Eb
34 mm
Raceway dimension
C
16,400 N
Basic dynamic load rating, axial
C0a
70,000 N
Basic static load rating, axial
cua
7,200 N
Fatigue load limit, axial
nG
7,500 1/min
Limiting speed
n ϑr
3,800 1/min
Reference speed
≈m
23.41 g
Weight
