IKO CF18WBUUR/SG
Maintenance Free Thrust Disk Cam Follower, Caged, High Carbon Steel, Crowned Outer Ring, Sealed, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
Order Number
CF18WBUUR/SG
Stud Diameter
18
mm
Outer Diameter
40
mm
Width
20
mm
Stud Diameter
18
mm
Thread
M18x1.5
Lenght
19.0
mm
Maximum width
21.6
mm
Max. Total lenght
58.1
mm
Lenght
36.5
mm
Dimension
8
Dimension
0.8
mm
Diameter
3
Dimension
8
mm
Min.Dimension related to the installation
29.0
mm
Max. Tightening torgue
86.2
Nm
Basic dynamic load rating
14800
N
Basic static load rating
25200
N
Max. Static allowable load
25200
N
Mass
250.0
g
The CF18WBUUR/SG Is an IKO Cam Follower
What product family does the CF18WBUUR/SG belong to?
The CF18WBUUR/SG is listed under IKO cam followers. The product series is Cam Followers, and the supplied data identifies the bearing type as Cam Followers and the internal structure as Cage Type.
The CF18WBUUR/SG Has Specified Dimensions and Fastening Details
What dimensions and thread information are provided?
The supplied data lists the following measurements:
- Stud diameter: 18 mm
- Outer diameter: 40 mm
- Width: 20 mm
- Thread: M18x1.5
- Length: 19.0 mm
- Maximum width: 21.6 mm
- Maximum total length: 58.1 mm
- Length: 36.5 mm
- Maximum tightening torque: 86.2 Nm
- Mass: 250.0 g
The CF18WBUUR/SG Includes Design and Load Data
What construction and load-rating details are available?
The product description identifies a maintenance free thrust disk cam follower with a crowned outer ring, seal, hex head, high carbon steel material, and caged construction. The supplied load data is:
- Basic dynamic load rating: 14800 N
- Basic static load rating: 25200 N
- Maximum static allowable load: 25200 N
