IKO CF101BRM

Standard Metric Cam Follower, Caged, High Carbon Steel, Crowned Outer Ring, Shielded, Hex Head, Fine Thread
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CF101BRM

Order Number CF10-1BR
Stud Diameter 10 mm
Inscribed circle diameter 10 mm
Outer Diameter 26 mm
Width 12 mm
Stud Diameter 10 mm
Thread M10x1.25 Length
12.0 mm
Maximum width 13.2 mm
Max.Total length 36.2 mm
Length 23.0 mm
Dimension - mm
Dimension 0.6 mm
Diameter - mm
Diameter - mm
Dimension 4.0 mm
rs min. - mm
Min.Dimension related to the installation 16.0 mm
Maximum tightening torque 13.80 Nm
Basic dynamic load rating 5430 N
Basic static load rating 6890 N
Max.Static allowable load 6890 N
Mass 60.0 g
