IKO CF12FBUUR
Standard Metric Cam Follower, Caged, Stainless Steel, Crowned Outer Ring, Sealed, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CF12FBUUR
Stud Diameter
12
mm
Outer Diameter
30
mm
Width
14
mm
Stud Diameter
12
mm
Thread
M12x1.5
Length
13.0
mm
Maximum width
15.2
mm
Max.Total length
40.2
mm
Length
25.0
mm
Dimension
6
mm
Dimension
0.6
mm
Diameter
6
mm
Diameter
3
mm
Dimension
6.0
mm
rs min.
-
mm
Min.Dimension related to the installation
21.0
mm
Maximum tightening torque
21.90
Nm
Basic dynamic load rating
6330
N
Basic static load rating
7830
N
Max.Static allowable load
7830
N
Mass
95.0
g
