IKO CF16B

Standard Metric Cam Follower, Caged, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CF16B

Order Number CF16B
Stud Diameter 16 mm
Inscribed circle diameter 16 mm
Outer Diameter 35 mm
Width 18 mm
Stud Diameter 16 mm
Thread M16x1.5 Length
17.0 mm
Maximum width 19.6 mm
Max.Total length 52.1 mm
Length 32.5 mm
Dimension 8 mm
Dimension 0.8 mm
Diameter 6 mm
Diameter 3 mm
Dimension 6.0 mm
rs min. 0.6 mm
Min.Dimension related to the installation 26.0 mm
Maximum tightening torque 58.50 Nm
Basic dynamic load rating 12000 N
Basic static load rating 18300 N
Max.Static allowable load 18300 N
Mass 170.0 g
