IKO CF18BUUR
Standard Metric Cam Follower, Caged, High Carbon Steel, Crowned Outer Ring, Sealed, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CF18BUUR
Stud Diameter
18
mm
Inscribed circle diameter
18
mm
Outer Diameter
40
mm
Width
20
mm
Stud Diameter
18
mm
Thread
M18x1.5
Length
19.0
mm
Maximum width
21.6
mm
Max.Total length
58.1
mm
Length
36.5
mm
Dimension
8
mm
Dimension
0.8
mm
Diameter
6
mm
Diameter
3
mm
Dimension
8.0
mm
rs min.
-
mm
Min.Dimension related to the installation
29.0
mm
Maximum tightening torque
86.20
Nm
Basic dynamic load rating
14800
N
Basic static load rating
25200
N
Max.Static allowable load
25200
N
Mass
250.0
g
