IKO CF201FB

Standard Metric Cam Follower, Caged, Stainless Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CF201FB

Order Number CF20-1FB
Stud Diameter 20 mm
Outer Diameter 47 mm
Width 24 mm
Stud Diameter 20 mm
Thread M20x1.5 Length
21.0 mm
Maximum width 25.6 mm
Max.Total length 66.1 mm
Length 40.5 mm
Dimension 9 mm
Dimension 0.8 mm
Diameter 8 mm
Diameter 4 mm
Dimension 8.0 mm
rs min. 1 mm
Min.Dimension related to the installation 34.0 mm
Maximum tightening torque 119.00 Nm
Basic dynamic load rating 16500 N
Basic static load rating 27700 N
Max.Static allowable load 27700 N
Mass 385.0 g
