IKO CF201VB
Cam Followers
Standard Metric Cam Follower, Full Complement, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com
REQUEST A QUOTE
Detailed data of Product
similar to product
Detailed data of
CF201VB
Cam Followers
Order Number
CF20-1VB
Stud Diameter
20
mm
Outer Diameter
47
mm
Width
24
mm
Stud Diameter
20
mm
Thread
M20x1.5
Length
21
mm
Length
7
mm
Length
2.0
mm
Maximum width
25.6
mm
Max.Total length
66
mm
Length
40
mm
Dimension
9
mm
Dimension
0.8
mm
Diameter
8
mm
Diameter
4
mm
Dimension
8
mm
rs min.
1.0
mm
Min.Dimension related to the installation
34
mm
Maximum tightening torque
119.0
Nm
Basic dynamic load rating
33200
N
Basic static load rating
64500
N
Max.Static allowable load
37500
N
Mass
390
g
