IKO CF201VUU

Standard Metric Cam Follower, Full Complement, High Carbon Steel, Cylindrical Outer Ring, Sealed, Screw Driver Slot,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CF201VUU

Order Number CF20-1VUU
Stud Diameter 20 mm
Outer Diameter 47 mm
Width 24 mm
Stud Diameter 20 mm
Thread M20x1.5 Length
21 mm
Maximum width 25.6 mm
Max.Total length 66.1 mm
Length 40.5 mm
Dimension 9 mm
Dimension 0.8 mm
Diameter 8 mm
Diameter 4 mm
rs min. 1.0 mm
Min.Dimension related to the installation 34 mm
Maximum tightening torque 119.0 Nm
Basic dynamic load rating 33200 N
Basic static load rating 64500 N
Max.Static allowable load 37500 N
Mass 390 g
