IKO CF301VB

Standard Metric Cam Follower, Full Complement, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CF301VB

Order Number CF30-1VB
Stud Diameter 30 mm
Outer Diameter 85 mm
Width 35 mm
Stud Diameter 30 mm
Thread M30x1.5 Length
32 mm
Length 7 mm
Length 2.0 mm
Maximum width 37.0 mm
Max.Total length 100 mm
Length 63 mm
Dimension 15 mm
Dimension 1.0 mm
Diameter 8 mm
Diameter 4 mm
Dimension 17 mm
rs min. 1.0 mm
Min.Dimension related to the installation 49 mm
Maximum tightening torque 438.0 Nm
Basic dynamic load rating 67700 N
Basic static load rating 144000 N
Max.Static allowable load 85900 N
Mass 2030 g
