IKO CF301VUUR
Standard Metric Cam Follower, Full Complement, High Carbon Steel, Crowned Outer Ring, Sealed, Screw Driver Slot,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CF30-1VUUR
Stud Diameter
30
mm
Outer Diameter
85
mm
Width
35
mm
Stud Diameter
30
mm
Thread
M30x1.5
Length
32
mm
Maximum width
37.0
mm
Max.Total length
100.0
mm
Length
63.0
mm
Dimension
15
mm
Dimension
1.0
mm
Diameter
8
mm
Diameter
4
mm
rs min.
1.0
mm
Min.Dimension related to the installation
49
mm
Maximum tightening torque
438.0
Nm
Basic dynamic load rating
67700
N
Basic static load rating
144000
N
Max.Static allowable load
85900
N
Mass
2030
g
