IKO CF3WBR
Thrust Disk Metric Cam Follower, Caged, High Carbon Steel, Crowned Outer Ring, Shielded, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CF3WBR
Stud Diameter
3
mm
Outer Diameter
10
mm
Width
7
mm
Stud Diameter
3
mm
Thread
M3x0.5
Length
5.0
mm
Maximum width
8.0
mm
Max.Total length
17.0
mm
Length
9.0
mm
Dimension
-
mm
Dimension
0.5
mm
Diameter
-
mm
Diameter
-
mm
Dimension
2.0
mm
Min.Dimension related to the installation
6.8
mm
Maximum tightening torque
0.34
Nm
Basic dynamic load rating
1500
N
Basic static load rating
1020
N
Max.Static allowable load
384
N
Mass
4.3
g
