IKO CFE101R
Eccentric Collar Metric Cam Follower, Caged, High Carbon Steel, Crowned Outer Ring, Shielded, Screw Driver Slot,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CFE10-1R
Diameter of the eccentricity color
13
mm
Outer Diameter
26
mm
Width
12
mm
Diameter of the eccentricity color
13
mm
Thread
M10x1.25
Dimension
10.5
mm
Maximum width
13.2
mm
Max.Total length
36.2
mm
Length
23.0
mm
Dimension
0.6
mm
Diameter
4
mm
Length
12.5
mm
rs min.
-
mm
Eccentricity
0.4
mm
Min.Dimension related to the installation
16
mm
Maximum tightening torque
13.8
Nm
Basic dynamic load rating
5430
N
Basic static load rating
6890
N
Max.Static allowable load
6890
N
Mass
65.0
g
