IKO CFE10VUUR
Eccentric Collar Metric Cam Follower, Full Complement, High Carbon Steel, Crowned Outer Ring, Sealed, Screw Driver Slot,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CFE10VUUR
Diameter of the eccentricity color
13
mm
Outer Diameter
22
mm
Width
12
mm
Diameter of the eccentricity color
13
mm
Thread
M10x1.25
Dimension
10.5
mm
Maximum width
13.2
mm
Max.Total length
36.2
mm
Length
23.0
mm
Dimension
0.6
mm
Diameter
4
mm
Length
12.5
mm
rs min.
0.3
mm
Eccentricity
0.4
mm
Min.Dimension related to the installation
16
mm
Maximum tightening torque
13.8
Nm
Basic dynamic load rating
9570
N
Basic static load rating
14500
N
Max.Static allowable load
8650
N
Mass
50.5
g
