IKO CFE12UUR
Eccentric Collar Metric Cam Follower, Caged, High Carbon Steel, Crowned Outer Ring, Sealed, Screw Driver Slot,
(BRAND)：IKO
(Availability)：In Stock
Order Number
CFE12UUR
Diameter of the eccentricity color
16
mm
Outer Diameter
30
mm
Width
14
mm
Diameter of the eccentricity color
16
mm
Thread
M12x1.5
Dimension
11.5
mm
Maximum width
15.2
mm
Max.Total length
40.2
mm
Length
25.0
mm
Dimension
0.6
mm
Diameter
6
mm
Length
13.5
mm
rs min.
-
mm
Eccentricity
0.8
mm
Min.Dimension related to the installation
21
mm
Maximum tightening torque
21.9
Nm
Basic dynamic load rating
7910
N
Basic static load rating
9790
N
Max.Static allowable load
9790
N
Mass
105.0
g
