IKO CFE20BR

Eccentric Collar Metric Cam Follower, Caged, High Carbon Steel, Crowned Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CFE20BR

Order Number CFE20BR
Diameter of the eccentricity color 27 mm
Outer Diameter 52 mm
Width 24 mm
Diameter of the eccentricity color 27 mm
Thread M20x1.5 Dimension
19.5 mm
Maximum width 25.6 mm
Max.Total length 66.1 mm
Length 40.5 mm
Dimension 0.8 mm
Diameter 8 mm
Length 21.0 mm
Dimension 8 mm
rs min. - mm
Eccentricity 0.8 mm
Diameter 4 mm
Min.Dimension related to the installation 34 mm
Maximum tightening torque 119.0 Nm
Basic dynamic load rating 20700 N
Basic static load rating 34600 N
Max.Static allowable load 34600 N
CETC1 0.000 mm
CETC2 0.000 mm
GD 0.000 mm
Mass 500.0 g
