IKO CFE20VBR

Eccentric Collar Metric Cam Follower, Full Complement, High Carbon Steel, Crowned Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CFE20VBR

Order Number CFE20VBR
Diameter of the eccentricity color 27 mm
Outer Diameter 52 mm
Width 24 mm
Diameter of the eccentricity color 27 mm
Thread M20x1.5 Dimension
19.5 mm
Maximum width 25.6 mm
Max.Total length 66.1 mm
Length 40.5 mm
Dimension 0.8 mm
Diameter 8 mm
Length 21.0 mm
Dimension 8 mm
rs min. 1.0 mm
Eccentricity 0.8 mm
Min.Dimension related to the installation 34 mm
Maximum tightening torque 119.0 Nm
Basic dynamic load rating 33200 N
Basic static load rating 64500 N
Max.Static allowable load 37500 N
CETC1 0.000 mm
CETC2 0.000 mm
GD 0.000 mm
Mass 505 g
