IKO CFE302VUUR

Eccentric Collar Metric Cam Follower, Full Complement, High Carbon Steel, Crowned Outer Ring, Sealed, Screw Driver Slot,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CFE302VUUR

Order Number CFE30-2VUUR
Diameter of the eccentricity color 41 mm
Outer Diameter 90 mm
Width 35 mm
Diameter of the eccentricity color 41 mm
Thread M30x1.5 Dimension
32.5 mm
Maximum width 37.0 mm
Max.Total length 100.0 mm
Length 63.0 mm
Dimension 1.0 mm
Diameter 8 mm
Length 30.5 mm
rs min. 1.0 mm
Eccentricity 1.5 mm
Min.Dimension related to the installation 49 mm
Maximum tightening torque 438.0 Nm
Basic dynamic load rating 67700 N
Basic static load rating 144000 N
Max.Static allowable load 85900 N
Mass 2380.0 g
