IKO CFE8B

Eccentric Collar Metric Cam Follower, Caged, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CFE8B

Order Number CFE8B
Diameter of the eccentricity color 11 mm
Outer Diameter 19 mm
Width 11 mm
Diameter of the eccentricity color 11 mm
Thread M8x1.25 Dimension
9.5 mm
Maximum width 12.2 mm
Max.Total length 32.2 mm
Length 20.0 mm
Dimension 0.6 mm
Diameter - mm
Length 10.5 mm
Dimension 4 mm
rs min. 0.3 mm
Eccentricity 0.4 mm
Diameter - mm
Min.Dimension related to the installation 13 mm
Maximum tightening torque 6.5 Nm
Basic dynamic load rating 4250 N
Basic static load rating 4740 N
Max.Static allowable load 4620 N
CETC1 3.500 mm
CETC2 8.000 mm
GD 4.000 mm
Mass 32.0 g
