IKO CFES18BR

Eccentric Stud Metric Cam Follower, Caged, High Carbon Steel, Crowned Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CFES18BR

Order Number CFES18BR
Stud Diameter 18 mm
Outer Diameter 40 mm
Width 20 mm
Stud Diameter 18 mm
Thread M18x1.5 Length
19 mm
Maximum width 21.6 mm
Max.Total length 58.1 mm
Length 36.5 mm
Dimension 8 mm
Dimension 0.8 mm
Diameter 6 mm
Diameter 3 mm
Dimension 8 mm
rs min. - mm
Eccentricity 0.60 mm
Min.Dimension related to the installation 29 mm
Maximum tightening torque 86.2 Nm
Basic dynamic load rating 14800 N
Basic static load rating 25200 N
Max.Static allowable load 25200 N
Mass 250.0 g
