IKO CFES18UU

Eccentric Stud Metric Cam Follower, Caged, High Carbon Steel, Cylindrical Outer Ring, Sealed, Screw Driver Slot,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CFES18UU

Order Number CFES18UU
Stud Diameter 18 mm
Outer Diameter 40 mm
Width 20 mm
Stud Diameter 18 mm
Thread M18x1.5 Length
19 mm
Maximum width 21.6 mm
Max.Total length 58.1 mm
Length 36.5 mm
Dimension 8 mm
Dimension 0.8 mm
Diameter 6 mm
Diameter 3 mm
rs min. 1 mm
Eccentricity 0.60 mm
Min.Dimension related to the installation 29 mm
Maximum tightening torque 86.2 Nm
Basic dynamic load rating 14800 N
Basic static load rating 25200 N
Max.Static allowable load 25200 N
Mass 250.0 g
