IKO CFKR30VR
Double Hex Metric Cam Follower, Full Complement, High Carbon Steel, Crowned Outer Ring, Shielded, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order number
CFKR30VR
Stud Diameter
12
mm
Outer Diameter
30
mm
Width
14
mm
Stud Diameter
12
mm
Thread
M12x1.5
Length
13
mm
Maximum width
15.2
mm
Max.Total length
40.2
mm
Length
25.0
mm
Dimension
6
mm
Dimension
0.6
mm
Diameter
4
mm
Diameter
3
mm
Dimension
6
mm
rs min
0.6
mm
Min.Dimension related to the installation
21
mm
Maximum tightening torque
21.9
Nm
Basic dynamic load rating
13500
N
Basic static load rating
19700
N
Max.Static allowable load
13200
N
Mass
96
g
