IKO CFKR80VUUR

Double Hex Metric Cam Follower, Full Complement, High Carbon Steel, Crowned Outer Ring, Sealed, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CFKR80VUUR

Order number CFKR80VUUR
Stud Diameter 30 mm
Outer Diameter 80 mm
Width 35 mm
Stud Diameter 30 mm
Thread M30x1.5
Length 32 mm
Maximum width 37.0 mm
Max.Total length 100.0 mm
Length 63.0 mm
Dimension 15 mm
Dimension 1.0 mm
Diameter 6 mm
Diameter 4 mm
Dimension 14 mm
rs min 1.0 mm
Min.Dimension related to the installation 49 mm
Maximum tightening torque 438.0 Nm
Basic dynamic load rating 67700 N
Basic static load rating 144000 N
Max.Static allowable load 85900 N
Mass 1860 g
