IKO CFKRE40

Eccentric Collar Double Hex Metric Cam Follower, Caged, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CFKRE40

Eccentric collar diameter 22 mm
Order number CFKRE40
Outer Diameter 40 mm
Width 20 mm
Thread M18x1.5 Length
19.0 mm
Maximum width 21.6 mm
Max.Total length 58.1 mm
Length 36.5 mm
Eccentric collar length 16 mm
Dimension 0.8 mm
Diameter 6 mm
Dimension 8.0 mm
rs min 1 mm
Eccentricity 1.0 mm
Min.Dimension related to the installation 29.0 mm
Maximum tightening torque 86.20 Nm
Basic dynamic load rating 14800 N
Basic static load rating 25200 N
Max.Static allowable load 25200 N
Mass 264.0 g
