IKO CFKRE47VUUR

Eccentric Collar Double Hex Metric Cam Follower, Full Complement, High Carbon Steel, Crowned Outer Ring, Sealed, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CFKRE47VUUR

Order number CFKRE47VUUR
Eccentric collar diameter 24 mm
Outer Diameter 47 mm
Width 24 mm
Thread M20x1.5 Length
21 mm
Maximum width 25.6 mm
Max.Total length 66.1 mm
Length 40.5 mm
Eccentric collar length 18 mm
Dimension 0.8 mm
Diameter 6 mm
Dimension 10 mm
rs min 1.0 mm
Eccentricity 1.0 mm
Min.Dimension related to the installation 34 mm
Maximum tightening torque 119.0 Nm
Basic dynamic load rating 33200 N
Basic static load rating 64500 N
Max.Static allowable load 37500 N
Mass 402 g
