IKO CFKRE85VUU
Cam Followers
Eccentric Collar Double Hex Metric Cam Follower, Full Complement, High Carbon Steel, Cylindrical Outer Ring, Sealed, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com
REQUEST A QUOTE
Detailed data of Product
similar to product
Detailed data of
CFKRE85VUU
Cam Followers
Order number
CFKRE85VUU
Eccentric collar diameter
35
mm
Outer Diameter
85
mm
Width
35
mm
Thread
M30x1.5
Length
32
mm
Maximum width
37.0
mm
Max.Total length
100.0
mm
Length
63.0
mm
Eccentric collar length
29
mm
Dimension
1.0
mm
Diameter
6
mm
Dimension
14
mm
rs min
1.0
mm
Eccentricity
1.5
mm
Min.Dimension related to the installation
49
mm
Maximum tightening torque
438.0
Nm
Basic dynamic load rating
67700
N
Basic static load rating
144000
N
Max.Static allowable load
85900
N
Mass
2080
g
