IKO CFS14WV
Thrust Disk Miniature Metric Cam Follower, Full Complement, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
Order Number
CFS1.4WV
Stud Diameter
1.4
Outer Diameter
4.0
Width
1.7
Stud Diameter
1.4
Thread
M1.4x0.3
Length
1.4
Width
3.7
Total Lenght
7.0
Length
3.3
Dimension
0.7
Dimension
0.9
Min.Dimension related to the installation
3.8
Maximum tightening torque
3.0
Basic dynamic load rating
481
Basic static load rating
385
Max.Static allowable load
105
Mass
0.35
