IKO CFS2V
Cam Followers
Miniature Metric Cam Follower, Full Complement, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com
REQUEST A QUOTE
Detailed data of Product
similar to product
Detailed data of
CFS2V
Cam Followers
Order Number
CFS2V
Stud Diameter
2.0
mm
Outer Diameter
4.5
mm
Width
2.5
mm
Stud Diameter
2.0
mm
Thread
M2x0.4
Length
2.0
mm
Width
4.0
mm
Total Lenght
8.0
mm
Length
4
mm
Dimension
0.7
mm
Dimension
0.9
mm
Min.Dimension related to the installation
4.3
mm
Maximum tightening torque
9.1
Nm
Basic dynamic load rating
768
N
Basic static load rating
734
N
Max.Static allowable load
229
N
Mass
0.6
g
