IKO CFS5
Miniature Metric Cam Follower, Caged, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
Order Number
CFS5
Stud Diameter
5.0
mm
Outer Diameter
10.0
mm
Width
6.0
mm
Stud Diameter
5.0
mm
Thread
M5x0.8
Length
5.0
mm
Width
8.0
mm
Total Lenght
18.0
mm
Length
10
mm
Dimension
1.0
mm
Dimension
2.0
mm
Min.Dimension related to the installation
9.6
mm
Maximum tightening torque
158.0
Nm
Basic dynamic load rating
1570
N
Basic static load rating
1850
N
Max.Static allowable load
1570
N
Mass
7.0
g
