IKO CFS5F
Miniature Metric Cam Follower, Caged, Stainless Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
Order Number
CFS5F
Stud Diameter
5.0
mm
Outer Diameter
10.0
mm
Width
6.0
mm
Stud Diameter
5.0
mm
Thread
M5x0.8
Length
5.0
mm
Width
8.0
mm
Total Lenght
18.0
mm
Length
10
mm
Dimension
1.0
mm
Dimension
2.0
mm
Min.Dimension related to the installation
9.6
mm
Maximum tightening torque
158.0
Nm
Basic dynamic load rating
1250
N
Basic static load rating
1480
N
Max.Static allowable load
1480
N
Mass
7.0
g
