IKO CFS6
Miniature Metric Cam Follower, Caged, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
Order Number
CFS6
Stud Diameter
6.0
mm
Outer Diameter
12.0
mm
Width
7.0
mm
Stud Diameter
6.0
mm
Thread
M6x1
Length
6.0
mm
Width
9.5
mm
Total Lenght
21.5
mm
Length
12
mm
Dimension
1.2
mm
Dimension
2.5
mm
Min.Dimension related to the installation
11.6
mm
Maximum tightening torque
268.0
Nm
Basic dynamic load rating
2090
N
Basic static load rating
2200
N
Max.Static allowable load
2150
N
Mass
13.0
g
