IKO CFS6W
Thrust Disk Miniature Metric Cam Follower, Caged, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CFS6W
Stud Diameter
6.0
Outer Diameter
12.0
Width
7.0
Stud Diameter
6.0
Thread
M6x1
Length
6.0
Width
10.5
Total Lenght
22.5
Length
12.0
Dimension
1.2
Dimension
2.5
Min.Dimension related to the installation
11.6
Maximum tightening torque
268.0
Basic dynamic load rating
2090
Basic static load rating
2200
Max.Static allowable load
1920
Mass
13.00
