IKO CFSFU12B

Easy Mount Metric Cam Follower, Caged, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CFSFU12B

Order Number CF-SFU-12B
Stud Diameter 12
Outer Diameter 30
Width 14
Stud Diameter 12
Maximum width 15.2
Max.Total length 35.0
Length 19.8
Dimension 0.6
Dimension 5
Dimension 10
H 6
Dimension 1.0
rs min. 0.6
Dimension related to the installation 12
Tolerance +0.018/0
Min.Dimension related to the installation 20
Min.Dimension related to the installation 21
Dimension related to the installation (reference) 10
Basic dynamic load rating 7910
Basic static load rating 9790
Max.Static allowable load 9790
Mass 94.0
