IKO CFSFU16
Easy Mount Metric Cam Follower, Caged, High Carbon Steel, Cylindrical Outer Ring, Shielded,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CF-SFU-16
Stud Diameter
16
mm
Outer Diameter
35
mm
Width
18
mm
Stud Diameter
16
mm
Maximum width
19.6
mm
Max.Total length
44.5
mm
Length
24.9
mm
Dimension
0.8
mm
Dimension
10
mm
Dimension
10
mm
Dimension
1.0
mm
rs min.
0.6
mm
Dimension related to the installation
16
mm
Tolerance
+0.018/0
Min.Dimension related to the installation
25
mm
Min.Dimension related to the installation
26
mm
Dimension related to the installation (reference)
15
mm
Basic dynamic load rating
12000
N
Basic static load rating
18300
N
Max.Static allowable load
18300
N
Mass
164.0
g
