IKO CFSFU8
Easy Mount Metric Cam Follower, Caged, High Carbon Steel, Cylindrical Outer Ring, Shielded,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CF-SFU-8
Stud Diameter
8
g
Outer Diameter
19
Width
11
Stud Diameter
8
Maximum width
12.2
Max.Total length
32.0
Length
19.8
Dimension
0.6
Dimension
5
Dimension
10
Dimension
0.5
rs min.
0.3
Dimension related to the installation
8
Tolerance
+0.015/0
Min.Dimension related to the installation
20
Min.Dimension related to the installation
13
Dimension related to the installation (reference)
10
Basic dynamic load rating
4250
N
Basic static load rating
4740
N
Max.Static allowable load
4620
N
Mass
29.0
