IKO CR12VBS
Inch Series Cam Followers, Full complement, High Carbon Steel, Cylindrical, Sealed with integrated thrust washer, Hex Head
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CR12VBS
Stud Diameter
9.525
mm
Outer Diameter
19.050
mm
Width
12.700
mm
Stud Diameter
9.525
mm
Thread
3/8-24
Length
9.525
mm
Maximum width
14.2
mm
Length
22.225
mm
Dimension
6.35
mm
Dimension
0.794
mm
Diameter
4.762
mm
Diameter
2.381
mm
Dimension
4.762
mm
rs min.
0.794
mm
Min.Dimension related to the installation
13.494
mm
Maximum tightening torque
10.8
Nm
Basic dynamic load rating
7400
N
Basic static load rating
11100
N
Mass
36
g
