IKO CR18VBS
Inch Series Cam Followers, Full complement, High Carbon Steel, Cylindrical, Sealed with integrated thrust washer, Hex Head
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CR18VBS
Stud Diameter
11.112
mm
Outer Diameter
28.575
mm
Width
15.875
mm
Stud Diameter
11.112
mm
Thread
7/16-20
Length
12.700
mm
Maximum width
17.3
mm
Length
25.400
mm
Dimension
6.35
mm
Dimension
0.794
mm
Diameter
4.762
mm
Diameter
3.175
mm
Dimension
6.350
mm
rs min.
1.588
mm
Min.Dimension related to the installation
19.050
mm
Maximum tightening torque
17.4
Nm
Basic dynamic load rating
12000
N
Basic static load rating
20300
N
Mass
100
g
