IKO CR28VBS
Inch Series Cam Followers, Full complement, High Carbon Steel, Cylindrical, Sealed with integrated thrust washer, Hex Head
(BRAND)：IKO
(Availability)：In Stock
Order Number
CR28VBS
Stud Diameter
19.050
mm
Outer Diameter
44.450
mm
Width
25.400
mm
Stud Diameter
19.050
mm
Thread
3/4-16
Length
22.225
mm
Maximum width
26.8
mm
Length
44.450
mm
Dimension
11.112
mm
Dimension
0.794
mm
Diameter
4.762
mm
Diameter
3.969
mm
Dimension
7.938
mm
rs min.
1.588
mm
Min.Dimension related to the installation
32.543
mm
Maximum tightening torque
100.0
Nm
Basic dynamic load rating
32200
N
Basic static load rating
49500
N
Mass
368
g
The IKO CR28VBS is an inch-series cam follower
What bearing type and brand is the CR28VBS?
The CR28VBS is an IKO cam follower in the Cam Followers product series. It is an inch-series, cylindrical, full-complement design made of high carbon steel and supplied sealed with an integrated thrust washer and hex head.
- Brand: IKO
- Model: CR28VBS
- Bearing type: Cam Followers
- Internal structure: Full complement
- Material: High Carbon Steel
The CR28VBS has specified stud, outer diameter, and width dimensions
What dimensions are listed for this cam follower?
The supplied data lists a 19.050 mm stud diameter, 44.450 mm outer diameter, and 25.400 mm width. Additional listed measurements include a 3/4-16 thread, 22.225 mm thread length, 44.450 mm overall length, 26.8 mm maximum width, and 1.588 mm minimum rs dimension.
- Stud diameter: 19.050 mm
- Outer diameter: 44.450 mm
- Width: 25.400 mm
- Thread: 3/4-16
- Mass: 368 g
The CR28VBS includes load rating and tightening data
What performance-related values are provided?
The product data lists a basic dynamic load rating of 32200 N and a basic static load rating of 49500 N. It also specifies a maximum tightening torque of 100.0 Nm and a minimum installation-related dimension of 32.543 mm.
- Basic dynamic load rating: 32200 N
- Basic static load rating: 49500 N
- Maximum tightening torque: 100.0 Nm
- Minimum installation-related dimension: 32.543 mm
